Wednesday, December 12, 2018

what is Open differential ?

Open differential:


 Basic concept:
the open differential is the most common type of differential. It shifts engine torque to two rear wheels equally.

Working principle:
When one wheel loses traction and slips on the ground, the opposing wheel also experiences a reduction in torque. In this case, your car gets stuck with one wheel spins freely while the other wheel with better traction can’t able to deliver enough torque to ride up the vehicle.

In cars and other wheeled vehicles, the differential permits the external drive wheel to pivot quicker than the internal drive wheel amid a turn. This is important when the vehicle turns, making the wheel that is going around the outside of the turning bend roll more distant and quicker than the other. The normal of the rotational speed of the two driving wheels levels with the info rotational speed of the drive shaft. An expansion in the speed of one wheel is adjusted by a decline in the speed of the other.


When the torque transmitted to the bevel pinion by the propeller shaft, it thusly drives the transverse ring apparatus of the differential. This additionally normally functions as decrease adapting. On rear wheel drive vehicles the differential connected with half-shafts, or drive shafts propells the driving wheels. Front wheel drive vehicles will in general have the motor crankshaft and the gearbox shafts transverse, and with the pinion on the finish of the principle shaft of the gearbox. There are singular drive-shafts to each wheel. A differential comprises of one information, the drive shaft, and two yields which are the two drive wheels, anyway the pivot of the drive wheels are coupled to one another by their association with the roadway. Under ordinary conditions, with little tire slip, the proportion of the paces of the two driving wheels is characterized by the proportion of the radii of the ways around which the two wheels are moving, which thusly is controlled by the track-width of the vehicle (the separation between the driving wheels) and the sweep of the turn.



Implemented in the following vehicles:
sedan vehicle, minivans, crossovers, economy cars, etc.
Open differential
Open differential



To know how a open differential works watch the video below:


what is Self Locking Differential ?

Self Locking Differential:
Process:
In this differential, the torque distributed to each wheel is controlled and during one wheel in the sand, mud, and snow condition the self-locking system locks one wheel that on the slip. And provides total torque to another wheel that on solid ground so that the vehicle can lift up.
It behaves like a normal open differential when not locked.

Used In below class vehicles:
Animation view of a Self-locking differential.
Animation view of a Self-locking differential.

To know how a self locking differential works, watch the video below:

Electronically Controlled Limited-slip Differential

 Electronically Controlled Limited-slip Differential

Basic Function:
An electronically controlled clutch type differential uses rheostatic control between open and fully locked situation, with adjustments are done hundreds of times per second with the help of computerized data analytics by analyzing the parameters like over-steer,  cornering forces, amount of torque, traction overcome by wheels etc.
thus it is different from a conventional limited-slip differential in which the torque is depended on slower wheel speed.

following vehicles use it:
BMW M3 and M4,  and CTS-VFerrari 488GTB,  Chevrolet Corvette,  Cadillac ATS-V.


The cross-sectional view of electronically limited slip differential
The cross-sectional view of electronically limited slip differential

Model of electronically limited slip differential.
Model of electronically limited slip differential.
To understand the process better, watch the video below:

what is torque-vectoring differential ?

 Torque-vectoring Differential:


What It Does:
This type of differential uses an additional gear-trains system to overdrive the two half-shafts or axles. Torque-vectoring differential fine-tunes the torque transmitted to each rear wheel. This produces a fine yaw moment that can be slow or quicken the car’s rotation during cornering.

These torque-vectoring differentials are more heavy, expensive and complex and reduce slight fuel-economy.
View of the torque-vectoring differential.
View of the torque-vectoring differential.

To understand the process better, watch the video below:



what is epicyclic differential ?

Epicyclic differential:

An epicyclic differential is simply a set of gear train arranged in a planetary system and emits various proportions of torque ratio according to the drive system.

Epicyclic equipping is utilized here to allow torque unevenly. The info shaft is the green empty one, the yellow is the low torque yield, and the pink is the high torque yield. The power connected in the yellow and the pink apparatuses is the equivalent, yet since the arm of the pink one is 2× to 3× as large, the torque will be 2× to 3× as high.
Epicyclic or planetary gear-train.
Epicyclic or planetary gear-train.

Epicyclic differential
Epicyclic differential
An epicyclic differential can utilize epicyclic adapting to part and allot torque unevenly between the front and back axles. An epicyclic differential is at the core of the Toyota Prius car drive train, where it interconnects the motor, engine generators, and the drive wheels (which have the second differential for part torque obviously). It has the benefit of being moderately minimized along the length of its pivot (that is, the sun outfit shaft).


  1. Epicyclic riggings are likewise called planetary apparatuses in light of the fact that the tomahawks of the planet gears spin around the basic pivot of the sun and ring gears that they work with and move between. In the picture, the yellow shaft conveys the sun outfit which is nearly covered up. The blue riggings are called planet gears and the pink apparatus is the ring apparatus or annulus.

To understand the process better, watch the video below:

Saturday, November 24, 2018

Types Of Car Differential

There are mainly six types of differentials used in a vehicle:

Normal differential.
Common Differential
  1. Open differential.
  2. Limited-slip Differential.
  3. Electronically Controlled Limited-slip Differential.
  4. Self-locking differential.
  5. Torque-vectoring Differential.
  6.  Epicyclic differential.


To know how a Differential works and types of differential watch the video below:



Friday, November 2, 2018

Limited Slip Differential

What is a limited slip differential:

A Limited slip differential is different from the normal differential. It has some unique features for uncertain road conditions. It is a revolutionary improvement for the differential. A special mechanical arrangement is added to it for Road conditions like one wheel on a slippery surface like ice and another wheel is on the ground. At that time this arrangement
locks one wheel that on the slippery surface so that the entire torque can be applied to the other wheel on the ground and the car lifts. This is what a limited slip differential does.

   internal view of limited slip differential
  internal view of a limited slip differential


The cross-sectional view of the limited-slip differential


It limits the amount of tough difference between the two axle shafts. It allows the two wheels to rotate on different speeds even they on the same axle.

This is very useful for off-road vehicles where the terrain is usually irregular and much more difficult to drive. This means one of the wheels of the vehicle might be on the solid ground while the other might be on the loose ground, now the wheel which is on the loose gravel requires less force to overcome friction and start spinning.  This would result in a loss of power in an open differential. Hence a limited slip set up is used.

Differential action during turning of vehicle.
 Cars take to turn on the road.
Differential action during turning of vehicle
 Cars take to turn on the road.



Limited-slip Differential:


It's a function:
A limited-slip differential based on the concepts of an open differential. It works like an open differential most of the time. As soon as slip occurs, it automatically begins to lock itself by viscous fluid and clutch pack, or with a complex gear-train.

The only mechanical limited-slip differential is not able to lock up itself until after wheel slips on the road.


Below model of vehicles uses it :
Nissan 370Z, Scion FR-S/Subaru BRZ, Mazda MX-5 Miata, model Scion FR-S/Subaru BRZ
Limited slip differential
Limited slip differential

Limited slip differential with friction clutches.
Limited slip differential with friction clutches.

To understand the process better, watch the video below:
